Eagle F5J XTail

$1,199.99

DESCRIPTION

RCRCM 3750mm Wingspan F5J Glider - Eagle

Eagle raise the bar to a new lever with higher quality, better fit and finish.



Available in 4 Versions:

Fiberglass+Carbon Standard Version: Standard hollow molded fiberglass construction reinforced with carbon fiber which gives good stiffness and torsion stability with lower weight and cost. Highly recommended for sport flying.

Carbon Version: Wings built using carbon cloth as well as fuselage reinforced with carbon from leading edge of the wing to the tail. This configuration gives the model enormous stiffness and torsion stability.

The first two versions are available in stock. We also can produce two custom versions; Light Carbon Version (less weight) and Double Carbon Version (with two layers of carbon).

Includes:

  • 3750mm Wingspan F5J Glider – Eagle
  • Ballast Tube(for Motorless Glider only) , Motor mount(for electric version only), servo support, Push Rod, Clevis, Linkage Rod, Control horn, Servo Cover, Wing joiner, tail joiner, servo plate.

SPECIFICATIONS:

Preferences                    Motor

Wingspan:                       3750mm

Length:                            1580mm

Wing area:                       81dm2

Flying Weight:                  N/A

Empty Weight:                 1700-1800g

CG:                                   81 mm from leading edge

Tow hook setting             NO

Ailerons                           YES

Elevator                          YES

Rudder                            YES

Flaps                               YES

Required Radio               No less than 7 channels



Recommend equipment configuration for an electric version basic configuration

Servos for wings              KST DS125MG*4

Servos for fuselage         KST DS215MG*2

Required Battery             6S 22.2V 3300mah 25C

Power System                 LC4250-12T KV410

Motor Mount Dia.             50mm

Electronic Speed Control SkyWalker-60A

Fairing size                      50mm

Propeller/EDF                 15*10

Paint Scheme is also available in a wide range of colors, besides standard color scheme presents on this website and can also include some other color schemes.

Another important thing about the surface of the glider: this RCRCM glider is fully moulded. Mould precision ensures that each glider has a complete aerodynamic layout but in the process of composite production, there is a slight chance of very tiny air bubbles or slight cloth grain. In the unlikely event that these small imperfections exist, they do not affect the structural strength or flight performance.

Glider long term storage: Hang glider vertically to reduce the stress on the glider surfaces to avoid deformation that could adversely affect flight performance and trim.

Eagle manual
